| CLUTCH |
|---|
| Dual plate, dry-type, with separate controls (pedal for transmission and hand lever for PTO), diameter of plates: 11 inch Plate facing of asbestos compound |
| TRANSMISSION |
|---|
| Gear box with constant-mesh gears: 8 forward and 2 reverse speeds |
| OPERATING WEIGHT |
|---|
| 2,100 KG |
| STEERING |
|---|
| Hydrostatic with independent circuit. Minimum turning radius: With brakes: 3,400 mm, Without brakes: 3,700 mm |
| CAPACITY |
|---|
| Fuel tank: 54 ltr, Engine oil: 11.5 ltr, Hydraulic Transmission: 18 ltr, Rear Axle: 4+4 ltr at both sides, Air Cleaner: 0.1 ltr, Power Steering: 1.5 ltr |
| TYRES |
|---|
| Front: 6.00-16 |
| Rear: 16.9/14-28 |
| OPTIONAL |
|---|
| AC Cabin, Canopy, Towing hook, Swinging Draw bar, Cold Starting aid, Front weight, High Clearance Kit, Low Clearance Kit, DTO pump applications and Creeper gear etc. |
| HYDRAULICS LIFT |
|---|
| With draft and position control, Draft control through top link. Gear type pump driven from engine crankshaft. Pump capacity (at 2,400 engine rpm): 24.8 l/min |
| Relief valve opening pressure: 190 kg/sq.cm: 3-point linkage Cat I – II Sway chains, Lift lever lock bracket. Max. Lifting capacity: 2,150 kg |
| ENGINE POWER |
|---|
| At flywheel 85 HP |
| SPEEDS (KPH) |
| With Tyres: 12.4/11-28 |
| Engine Speed (rpm): 2,160–2,500 |
| Pto Speed (rpm): 540 |
| FILTERS |
|---|
| Air: Oil-bath with pre-cleaner and Semiautomatic dust unloader |
| Fuel: 2 replaceable cartridges |
| ENGINE |
|---|
| New Holland 8045.05 |
| 4-Stroke, direct injection diesel engine |
| Number of cylinder: 4 |
| Bore and stroke: 100 x 115 mm |
| Piston Displacement: 3,613cc |
| Compression ratio: 17:1 |
| Max. Torque at 1,500 rpm: 29.9 kgm |
| CLUTCH |
|---|
| Dual plate, dry-type, with separate controls (pedal for transmission and hand lever for PTO), diameter of plates: 11 inch Plate facing of asbestos compound |
| TRANSMISSION |
|---|
| Gear box with constant-mesh gears: 8 forward and 2 reverse speeds |
| OPERATING WEIGHT |
|---|
| 2,100 KG |
| STEERING |
|---|
| Hydrostatic with independent circuit. Minimum turning radius: With brakes: 3,400 mm, Without brakes: 3,700 mm |
| CAPACITY |
|---|
| Fuel tank: 54 ltr, Engine oil: 11.5 ltr, Hydraulic Transmission: 18 ltr, Rear Axle: 4+4 ltr at both sides, Air Cleaner: 0.1 ltr, Power Steering: 1.5 ltr |
| TYRES |
|---|
| Front: 6.00-16 |
| Rear: 16.9/14-28 |
| OPTIONAL |
|---|
| AC Cabin, Canopy, Towing hook, Swinging Draw bar, Cold Starting aid, Front weight, High Clearance Kit, Low Clearance Kit, DTO pump applications and Creeper gear etc. |
| HYDRAULICS LIFT |
|---|
| With draft and position control, Draft control through top link. Gear type pump driven from engine crankshaft. Pump capacity (at 2,400 engine rpm): 24.8 l/min |
| Relief valve opening pressure: 190 kg/sq.cm: 3-point linkage Cat I – II Sway chains, Lift lever lock bracket. Max. Lifting capacity: 2,150 kg |
| ENGINE POWER |
|---|
| At flywheel 85 HP |
| SPEEDS (KPH) |
| With Tyres: 12.4/11-28 |
| Engine Speed (rpm): 2,160–2,500 |
| Pto Speed (rpm): 540 |
| FILTERS |
|---|
| Air: Oil-bath with pre-cleaner and Semiautomatic dust unloader |
| Fuel: 2 replaceable cartridges |
| ENGINE |
|---|
| New Holland 8045.05 |
| 4-Stroke, direct injection diesel engine |
| Number of cylinder: 4 |
| Bore and stroke: 100 x 115 mm |
| Piston Displacement: 3,613cc |
| Compression ratio: 17:1 |
| Max. Torque at 1,500 rpm: 29.9 kgm |
