PERFORMANCE:
BRAKES
| CLUTCH |
|---|
| Type: Dual |
| TRANSMISSION |
|---|
| No. of Gears: 8 Forward, 2 Reverse |
| BRAKES |
|---|
| Type: Oil Board Drum Brakes Independent or locked together. |
| HYDRAULICS |
|---|
| Max. Lift Force: 1415 Kg (3120 lbs.) |
| Functions: Draft Control, Piston Control |
| TYRES |
|---|
| Front: 6.00 – 16 (6PR) Pressed Wheels |
| Rear: 12.4/11 – 28 (6PR) Pressed Wheels |
| WEIGHT |
|---|
| Gross Weight (Approx) 1,650 kg |
| Diameter: 305X254 mm |
| STANDARD FITTINGS |
|---|
| Weight Frame without weight, Standaed Tool Box with set of Tools, Top Link, End Cat I & II Balls, Check Chains, Spring Suspension Seat, Flat Top Fenders. Operators and Service Manual |
| OPTIONAL EQUIPMENT |
|---|
| 9-Hole Draw Bar, Stays, Fiber Glass Top Sun Canopy with Frame, Ground PTO, Frond End Weights, Rear View Mirror, Swinging Draw Bar, Pintle Hook. |
| ENGINE |
|---|
| Make/Model: Perkins/AD 3.1524 |
| Type: Diesel |
| No. of Cylinders: 3 |
| Cooling: Water |
| Air Cleaner: Oil Bath |
| Air pre-cleaner: Over-bonnet |
| CAPACITIES |
|---|
| Fuel Tank: 47.5 liters |
| Engine Sump: 6.8 liters |
| HHydraulics: 33 liters |
| Steering Box: 0.9 liters |
| PERFORMANCE |
|---|
| Engine HP @ 2200 RPM: 50 (BS)* |
| Max. Torque @ 1350 RPM: 172 Nm |
| P.T.O HP @ rated Engine Speed: 44 hp* |
PERFORMANCE:
BRAKES
| CLUTCH |
|---|
| Type: Dual |
| TRANSMISSION |
|---|
| No. of Gears: 8 Forward, 2 Reverse |
| BRAKES |
|---|
| Type: Oil Board Drum Brakes Independent or locked together. |
| HYDRAULICS |
|---|
| Max. Lift Force: 1415 Kg (3120 lbs.) |
| Functions: Draft Control, Piston Control |
| TYRES |
|---|
| Front: 6.00 – 16 (6PR) Pressed Wheels |
| Rear: 12.4/11 – 28 (6PR) Pressed Wheels |
| WEIGHT |
|---|
| Gross Weight (Approx) 1,650 kg |
| Diameter: 305X254 mm |
| STANDARD FITTINGS |
|---|
| Weight Frame without weight, Standaed Tool Box with set of Tools, Top Link, End Cat I & II Balls, Check Chains, Spring Suspension Seat, Flat Top Fenders. Operators and Service Manual |
| OPTIONAL EQUIPMENT |
|---|
| 9-Hole Draw Bar, Stays, Fiber Glass Top Sun Canopy with Frame, Ground PTO, Frond End Weights, Rear View Mirror, Swinging Draw Bar, Pintle Hook. |
| ENGINE |
|---|
| Make/Model: Perkins/AD 3.1524 |
| Type: Diesel |
| No. of Cylinders: 3 |
| Cooling: Water |
| Air Cleaner: Oil Bath |
| Air pre-cleaner: Over-bonnet |
| CAPACITIES |
|---|
| Fuel Tank: 47.5 liters |
| Engine Sump: 6.8 liters |
| HHydraulics: 33 liters |
| Steering Box: 0.9 liters |
| PERFORMANCE |
|---|
| Engine HP @ 2200 RPM: 50 (BS)* |
| Max. Torque @ 1350 RPM: 172 Nm |
| P.T.O HP @ rated Engine Speed: 44 hp* |
