| CLUTCH |
|---|
| Dual plate, dry-type, with separate controls (pedal for transmission and hand lever for PTO), diameter of plates: 11 inch |
| Plate facing of asbestos compound |
| TRANSMISSION |
|---|
| Gear box with constant-mesh gears: 8 forward and 2 reverse speeds |
| STEERING |
|---|
| Hydrostatic with independent circuit. Minimum turning radius: with brakes: 3,000 mm , without brakes: 3,800 mm |
| CAPACITY |
|---|
| Fuel Tank: 61.01 Engine Oil sump and filter: 7.311 Rear transmission and Hydraulic lift: 30.11 |
| OPTIONAL |
|---|
| AC Cabin, Canopy, Towing hook, Swinging Draw bar, Cold Starting aid, Front weight, High Clearance Kit, Low Clearance Kit, DTO pump applications and Creeper gear etc. |
| TYRES |
|---|
| Front: 6.00-16 |
| Rear: 14.9/13-28 |
| ENGINE POWER |
|---|
| At flywheel 55 HP |
| HYDRAULICS LIFT |
|---|
| Lift-o-matic, automatic, with draft, position and mixed control, draft control through the top link, pump capacity 34.5 L/min. (Max.) Relief Valve opening pressure, 190 kg/cm2 Automatic lifting and lowering device. Lowering Speed Adjustment and transport lock, Lifting capacity: 2200 kg. |
| ENGINE |
|---|
| New Holland 8035.05 |
| 4-Stroke, direct injection diesel engine |
| Number of cylinder: 3 |
| Bore and stroke: 100 x 115 mm |
| Piston Displacement: 2,710cc |
